Rev. 5 91
Operation
Summary of Operational Limits
References to the specifications indicate that the absolute limit is
determined by the specific configuration of the Model 430 Programmer
purchased.
Table 3-7. Summary of Model 430 Programmer Limits and Defaults
Model 430 Setting (Units) Absolute Limits Default Setting
a
a. Unless preset by factory.
Min Output Voltage (V)
0.000 to
-20.000
-6.000
Max Output Voltage (V) 0.001 to +20.000 6.000
Min Output Current (A)
see table on
page 8
-125.000
Max Output Current (A)
see table on page 8
125.000
V-V Mode Input Range (V)
-10.000 to +10.000
-10.000 to +10.000
Stability Setting (%) 0.0 to 100.0 0.0
Coil Constant (kG/A) 0.001 to 999.99999 1.0
PSwitch Current (mA) 0.0 to 125.0 10.0
PSwitch Heated Time (sec)
5 to 120 20
PSwitch Cooled Time (sec)
5 to 3600 20
PSwitch Power Supply
Ramp Rate (A/sec)
same as min and max ramp
(see table on
page 8)
10
PSwitch Cooling Gain
0.0 to 100.0 0.0
Magnet Current Rating (A)
+/-0.001 to +/-
9999.9999999999
80.000
Current Limit (A)
≥ Min Output Current and
≤ Max Output Current
80.000
Display Brightness (%) 25, 50, 75, 100 100
Voltage Limit (V)
≥ 0.001 and
≤ Max Output Voltage
2.000
Ramp Rate (A/sec)
see table on
page 8
0.100
Target Current (A)
≤ Current Limit
5.000
