User/Installation Manual StandAlone Mechanical Card Reader Model #’s 11-024 & 11-024i “Your Partner in Access Control” www.americanaccess.
AAS 2-Year Limited Warranty This warranty applies to all product or equipment specifically and solely designed for and manufactured by American Access Systems, Inc. Any equipment used in AAS products that is not manufactured by American Access Systems, Inc. (this includes all products purchased by AAS for OEM purposes) is liable and subject to warranty terms of that specific manufacturer.
Technical/Customer Support 1-303-799-9757 or techsupport@securitybrandsinc.com SECURITY BRANDS INC 1675 West Yale Ave. Englewood, CO 80110 phone: 303-799-9757 fax: 303-799-9756 sales@securitybrandsinc.com www.securitybrandsinc.com Page 3 American Access Systems / Security Brands, Inc.
WIRING DIAGRAM BLACK READER MODULE TO GATE OPERATOR WHITE NIGHT LIGHT HOOKUP 12 OR 24 VOLT SOURCE FROM GATE OPERATOR 100 OHM 10 WATT USE RESISTOR IF VOLTAGE SOURCE IS 24 VOLTS. Page 4 American Access Systems / Security Brands, Inc.
THE IDLE MODE The idle mode is the mode of operation in which the unit sits and waits for data from the keypad. When a key is pressed you will have approximately 3 seconds between keypresses before the unit resets. THE LED’s The yellow LED serves as a ready indicator and stays lit while the 12-000 is waiting for data from the keypad. When a key is pressed the yellow led will go out until either 5 numeric keys are pressed on the keypad or a time of 3 seconds is exceeded between keypresses.
BRASS NUT MOUNTING BRACKET PROGRAM CARTRIDGE CARD READER MODULE INSTRUCTIONS Remove the brass screws and slip the reader module from mounting bracket Place the program cartridge between the reader module and the mounting brackets and reassemble the unit SPECIFICATIONS • Power requirement: None unless night light is desired • Switching capacity: • Switching Logic: Normally Open • Ambient Temperature: • Humidity: Non Condensing - 35% maximum • Note: 5 Amp 250 VAC or 5 Amp 26 VDC Up to 180 Deg
Customer Service and Tech Support Customer Service: 303-799-9757 Customer service is available free of charge. Hours are 8:00 a.m. to 4:30 p.m. MST. If you call, please have your Model and Serial Number to help our Technicians assist you. E-Mail: customerservice@securitybrandsinc.com Technical Support: 303-799-9757 Technical support is available free of charge. Hours are 8:00 a.m. to 4:30 p.m. MST. If you call, please have your Model and Serial Number to help our Technicians assist you.
