Users Guide 34
DHCP Remaining Time:
Display the remained DHCP lease time before expiration.
Refresh
Click to refresh the information.
LOCAL SETTINGS
Gateway IP Address:
Display the local IP address of the LAN interface.
Subnet Mask:
Display the subnet mask value.
DHCP Server:
Display the status of DHCP sever feature.
No Server Allowed :
?????
NAT
Display if NAT mode is enabled.
Wireless Status
Display if the wireless feature is active.
Operation Mode
Display the mode the router is running, NAT mode, or Router mode.
IP Range
Display the private IP address scale.
System Up-Time:
Display the accumulated time since the last power cycle.
7.3 Wireless
7.3.1 Basic
This page allows configuration of the Wireless Modem parameters the SSID and channel
number. A wireless LAN can be as simple as two computers with wireless LAN adapters
communicating in a peer-to-peer network or as complex as a number of computers with wireless
LAN adapters communicating through access points which bridge network traffic to the wired
LAN.
Label
Description
Wireless MAC Address
Display MAC address of wireless router’s wireless module.
Network Name (SSID)
The SSID identifies the Service Set with which a wireless station is
associated. Wireless stations associating to the wireless router must have
the same SSID.
Broadcast SSID
Click Enable to allow broadcast of SSID.
