Users Manual Panel Heater (HPB-4E) Please read this manual carefully before use
IMPORTANT SAFEGUARDS When using an electrical appliance, basic safety precautions should always be observed, including the following: READ ALL INSTRUCTIONS BEFORE USING WARNING: To reduce the risk of fire, electrical shock, or injury to person: 1. The product is for household use only. 2. Connect the appliance to single-phase AC supply of the voltage specified on the rating plate. 3. In order to avoid overheating do not cover the heater. 4. Never leave the heater unattended while it is in use.
SPECIFICATIONS MODEL NO NET SIZE RATED VOLTAGE HPB-4E 870X400X70MM ~230V/50Hz STRUCTURE AND PARTS RATED POWER 1800W
CHARACTERISTIC Over heating protection Water proof IPX4 For wall-mount use or stand alone option With digital LCD Room temperature setting Room temperature sensor Digital clock, digital week calendar Multi-running mode: daily program mode, weekly program mode, free use mode 9. anti-frost function 1. 2. 3. 4. 5. 6. 7. 8. INSTALLATION NOTE：USED AS WALL-MOUNTED ONLY a. Drill holes on the wall according to the picture (1). Warning: Please insure that the heater is mounted 30mm above the floor b.
INSTRUCTIONS FOR USE Warning before using the heater make sure that it is mounted tightly on the wall. Damage may occur if it is mounted on an incline or decline. 1.
Economic Anti-frost OFF daily program running mode program contents weekly program running mode heating program setting lock solid time mark 2.Rationale: (1)There are 3 working modes: comfort ,economic and anti-frost （5°C）. (2) There are in total 11 programs: a. 9 daily programs(P1-P9) b. weekly program(AU) c. free program(Fr) (3) there are 3 running modes for you to select: a. daily program running mode(D) b. weekly program running mode(AU) c.
6. Select running mode Press , then press or to select running mode as follows (showing on screen): a. P1-P9 plus D :daily program running mode (Every day will repeat this program as running mode.) b. Fr : free running mode (You may set a program for today use. Then it will return to anti-frost mode automatically after using.) c. AU: weekly program running mode (Every day will run the relevant daily program as selected, while setting and repeating weekly). Then confirm it with . 7.
means you are ready to set the program (during this period, unit will stop heating) Press to select working mode（ economic； and and mean comfort； and mean anti-frost），then press mean to copy the working mode one segment by one segment. Press & Hold (for approximately 3 seconds) to finish the program setting and unit will return to normal running. Note: the contents of free program will not be kept in the memory and will return to anti-frost working mode after running. 9.
Please see the explanation below these are the times the heater operates in comfort mode: • P1 3.00pm – 11.00pm • P2 7.00am – 12.00(Midnight) • P3 7.00am – 11.00pm • P4 5.00am – 7.00am then 9.00pm – 11.00pm • P5 7.00am – 9.00am then 10.00pm – Midnight • P6 7.00am – 9.00am then 9.00pm – 11.00pm • P7 6.00am – 4.00pm • P8 Frost Mode Only • P9 Constant 24 hours N.B When choosing a program For Example P4. The unit will heat on comfort temperature 5.00am – 7.00am and then again at 9.00pm – 11.00pm. From 11.
4. To store the heater, put the heater back into its original package and store it in a clean dry place. 5. In case of malfunction or doubt, do not try to repair the heater yourself, it may result in a fire hazard or electric shock. CONFORMITY WITH DIRECTIVES This product is CE marked to denote conformity with Directives 73/23/EEC (Low Voltage) and 89/336/EEC (Electromagnetic Compatibility), as amended. Waste electrical products should not be disposed of with household waste.
