Heavy Duty Commercial

Compact [0.6 Cubic Foot]

Microwave Oven

Keep these instructions for future reference.

If the oven changes ownership, this manual must

accompany oven.

Owner's ManualOwner's Manual

Owner's Manual

Contents

Model Identification .......................... 2

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE

TO EXCESSIVE

MICROWAVE

ENERGY .................. 3

IMPORTANT SAFETY INSTRUCTIONS .. 3

Earthing Instructions ......................... 5

Installation ........................................ 5

Display and Features........................ 6

Using the Oven Control .................... 8

Programming the Oven Control ........ 9

User Options ...................................10

Care and Cleaning ..........................12

Before Calling for Service ................ 13

Summary of content (12 pages)

PAGE 1
Owner's Manual Contents Model Identification .......................... 2 PRECAUTIONS TO AVOID POSSIBLE Heavy Duty Commercial Compact [0.6 Cubic Foot] Microwave Oven Keep these instructions for future reference. If the oven changes ownership, this manual must accompany oven. EXPOSURE TO EXCESSIVE MICROWAVE ENERGY .................. 3 IMPORTANT SAFETY INSTRUCTIONS .. 3 Earthing Instructions ......................... 5 Installation ........................................ 5 Display and Features .........
PAGE 2
Model Identification Complete enclosed registration card and promptly return. If registration card is missing, call Consumer Affairs Department at 1-800-843-0304 inside U.S.A. 1-319-622-5511 outside U.S.A. Any questions or to locate an authorized servicer, call 1-800-843-0304 inside U.S.A. 1-319-622-5511 outside U.S.A. If an automated telephone system is reached, select Commercial Microwave Ovens category. Warranty service must be performed by an authorized servicer.
PAGE 3
IMPORTANT SAFETY INSTRUCTIONS Recognize this symbol as a SAFETY message ! WARNING When using electrical equipment, basic safety precautions should be followed to reduce the risk of burns, electrical shock, fire, or injury to persons. 1. READ all instructions before using equipment. 9. DO NOT heat baby bottles in oven. 2. READ AND FOLLOW the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” on this page. 10.
PAGE 4
IMPORTANT SAFETY INSTRUCTIONS ! WARNING ! WARNING Liquids such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
PAGE 5
Installation Unpacking Oven • • • • Inspect oven for damage such as dents in door or inside oven cavity. Report any dents or breakage to source of purchase immediately. Do not attempt to use oven if damaged. Remove all materials from oven interior. If oven has been stored in extremely cold area, wait a few hours before connecting power. Radio Interference Microwave operation may cause interference to radio, television, or a similar oven.
PAGE 6
Display and Features X Single Pad Programming Start Pad The start pad is used to begin a manual time entry cooking cycle. It is also used to save any changes to programming sequences or user options. This feature enables each numbered pad to be programmed for a specific use, such as cooking a certain number of potatoes or defrosting and then cooking vegetables or other frozen foods. To use this feature, simply program the pad to the desired length of time and power level.
PAGE 7
Display and Features Cooking Display DISPLAYS DESCRIPTION READY READY displays when oven control will accept entries. 00:00 Displays cooking time. If stage cooking is programmed, total cooking time is displayed. COOK LEVEL The display is used for many COOK LEVEL displays while oven is operating. different models of The cooking level is displayed above as a number 1 microwaves. Depending on the model, through 9.
PAGE 8
Using the Oven Control Interrupting Operation Open oven door or press STOP/RESET pad to interrupt operation. Display continues to show countdown time. Close door and press START pad to resume oven operation. Canceling Mistakes • If oven is not cooking, press STOP/RESET pad to clear display. If oven is cooking, press STOP/RESET pad once to stop oven, then again to clear display. If oven door is open and time shows in display, close oven door and press STOP/RESET pad to clear display.
PAGE 9
Programming the Oven Control Programming Pads Oven is shipped from the factory for single pad programming. To change the oven default to allow double pad programming, see User Options. To change the amount of time or the power level for a preset pad: 1. Open oven door. • READY displays. • If door is closed or RESET pad is pressed before programming is complete, changes are discarded and microwave exits programming mode. 2. Press and hold pad 1 for approximately 5 seconds. • This begins programming mode.
PAGE 10
User Options Didn’t like an option? Changing user options Factory settings are marked in bold. To change the oven back to the factory setting, simply select the option that is marked in bold. Options such as single or double pad programming, beep volume, and maximum cooking time can be changed to suit individual preferences. To change options: My changes weren’t saved. In order for any changes to be saved, the START pad must be pressed after selecting an option.
PAGE 11
Care and Cleaning Replacing Oven Light 1. Disconnect electrical supply. 2. Remove screw from side of oven. 3. While wearing protective gloves, turn light bulb counterclockwise to remove. 4. Replace light bulb with 230-volt, 25-watt appliance bulb. Do not over-tighten bulb. Over-tightening may make bulb difficult to remove later. 5. Replace light bulb cover before use. 6. Reconnect power supply.
PAGE 12
Before Calling for Service ! WARNING To avoid electrical shock which can cause severe personal injury or death, do not remove outer case at any time. Only an authorized servicer should remove outer case. An authorized servicer MUST inspect equipment annually. Record all inspections and repair for future reference. Problem Possible Cause Confirm oven is plugged into dedicated circuit. Oven does not operate. Confirm oven is on grounded and polarized circuit.
