Parameters Summary
Voice Gateways System Manual 75
H323 Alias
(H323 model only)
A string of up to 25 characters Null
Telephone domain name
(SIP model only)
A string of up to 25 characters Null
Port
(SIP model only)
1030-65535 Line 1: 5060
Line 2: 5061
Message Waiting Account
(SIP model only)
Null
Incoming CLIP On/Off Off
Keepalive timeout 10-65535 seconds 1200 seconds
Ring signal 0-9 0
Transport
(SIP model only)
UDP/TCP UDP
Codecs and Fax Configuration
Jitter Buffer:
Adaptive Jitter Buffer 100-300 milliseconds 100 milliseconds
Fixed Jitter Buffer 100-300 milliseconds 40 milliseconds
Automatically switch to Fixed Jitter
Buffer
Yes (checked)/No
(unchecked)
Unchecked
Codec:
G711A Select/Deselect Yes (checked)/No(unchecked) Yes (checked)
SS Not applicable
EC Enable/Disable Enabled
Packet 10-150 milliseconds 20 ms
Keypad SIP: None, RFC2833,
SIP INFO
H323: H225, H245, RFC2833,
None
None
Priority 1-3 1
Table 3-18: Parameters Summary
Parameter Range/Options Default
