70 Operation
Chapter 3 - Using the Web Configuration Server
bit-4 (0x10): TFTP session failed
bit-5 (0x20): CRC error in downloaded image
bit-6 (0x40): incompatible image
3.10.1.1 Examples
An attempt to download from a non-existing TFTP-server results in code 0x7 (=
0x07):
bit-2 0x04 TFTP server not defined plus…
bit-1 0x02 failed to download new image plus…
bit-0 0x01 upgrade requested or main application not valid
An attempt to download a non-existing file results in code 0xb (= 0x0b):
bit-3 0x08 TFTP file not defined plus…
bit-1 0x02 failed to download new image plus…
bit-0 0x01 upgrade requested or main application not valid
A successful download results in code 0x01
A restart without download of main application results in 0x00.
