68 Operation
Chapter 3 - Using the Web Configuration Server
3.10 Upgrade Page
The Upgrade page enables to control the process of downloading either a software
file (with the extension .ro) or a configuration file (with the extension .ini) from a
TFTP-server or from an HTTP server.
The Upgrade page includes the following components:
Click on the
Start Auto/HTTP/TFTP Upgrade button to start the download
process. The downloading and installation of the new SW version or configuration
Figure 3-26: Upgrade Page
Table 3-17: Upgrade Page Parameters
Parameter Description
Upgrade Type Auto The Voice Gateway will automatically select the server type for
download.
TFTP Downloads the file from the TFTP server according to the
specified host address.
HTTP Downloads the file from the HTTP server according to the
specified URL. Not implemented in the current release.
Host (TFTP) The IP address of the TFTP server
URL (HTTP/Auto) Use the following syntax: IP/filename. E.g.,
192.168.254.1/DMA0027R2F201.ro
File name The file name in the HTTP/TFTP server of the software or the
configuration .ini file. Up to 25 characters.
