System Menu
Voice Gateways System Manual 65
3.9.3 SNMP Configuration Page
The SNMP Configuration page includes the following components:
Figure 3-23: SNMP Configuration Page
Table 3-16: SNMP Configuration Page Parameters
Parameter Description
SNMP Trap Configuration
Trap Destination 1 to Trap
destination 6
Specify up to 6 IP addresses to which SNMP traps should be sent.
Only these stations will be able to manage the Voice Gateway. If
all Trap Destinations are null, SNMP traps will be sent as
broadcasts, and any station will be able to manage the Voice
Gateway.
SNMP MIB Parameter Configuration
