6 System Description
Chapter 1 - System Description
1.2.9 Regulatory Standards Compliance
1.2.10 Environmental
WAN Type 10/100Base-TX (RJ-45)
Ethernet Connection to SU-IDU/hub:
Straight
Cable Length max 100 m.
12 VDC Standard DC power jack to external power supply
Table 1-9: Standards Compliance
Type Standard
EMC Low Voltage Directive (LVD) 73/23/EEC
Electromagnetic Compatibility Directive (EMC)
89/336/EEG
Safety IEC 60950
CSA C22.2 No. 950-95/UL 1950
AS/NZS 3260
Emission EN 55022:1998 Class B
EN 61000-3-2:1995
Harmonics; EN 61000-3-3:1995
Flicker; FCC part 15 (1998) Class B
AS/NZS 3548 (1995)
Immunity EN 55024:1998
Table 1-10: Environmental Specifications
Item Details
Operating temperature 0 o C to 50 o C
Operating humidity 10%-95% RH non condensing
Table 1-8: Connectors
Connection Description
