Specifications
Voice Gateways System Manual 5
1.2.6 Mechanical
1.2.7 Electrical
1.2.8 Connectors
Unknown address Forwarding
Policy
Forward Unknown
Bridge Aging Time 180 seconds
Table 1-6: Mechanical Specifications
Item Details
Dimensions (W x D x H) 17.6 x 11 x 2.8 cm
Weight 230g
Table 1-7: Electrical Specifications
Item Details
Power Input 12 VDC from an external power supply, 100-240 VAC,
50-60 Hz, 2A max.
Power Consumption 10.5 W max.
Table 1-8: Connectors
Connection Description
LAN Type 10/100Base-TX (RJ-45)Ethernet
connection: MDI/MDIX
Cable Length max 100 m.
PHONE
(1 - 2 in VG-1D2V)
Type RJ-11
Number of Phones (REN) Up to 5
Cable Length Max. 500 m
Table 1-5: Bridge Functionality
Item Description
