User's Manual

Chapter 4 - Operation and Administration BTS Menu
BreezeMAX Extreme 79 System Manual
* The frequency 5725 MHz is illegal and cannot be used.
4.5.3.5.8 DFS
The DFS option is applicable only for units operating in the 5 GHz frequency
bands using a Band Name specifying that DFS should be used. The DFS feature is
managed separately for each sector (see “DFS” on page 128). The BTS level DFS
parameters are common to both sectors (if applicable) and it includes the
following parameters:
 DFS Type
 Frequencies Management Level
4.5.3.5.8.1 DFS Type
The DFS Type parameter defines the DFS algorithm to be used. This read-only
parameter is set according to the DFS type specified in the selected Band Name.
The available DFS algorithm (according to the selected Band Name) are:
 ETSI/FCC: The algorithm searches (passive listening) for radar signals
according to relevant ETSI or FCC regulations. To increase the probability of
radar detection for compliance with the relevant regulations, additional silence
zone is added to the uplink at the expense of slightly reduced throughput in
the downlink. This means that although the specified DL-UL Ratio is 60-40,
Table 4-3: Band Name’s Dependent Parameters, 5.4 GHz Units
Band Name Frequency Range
(MHz)
Maximum EIRP (dBm) Supported
DFS
5 MHz BW 10 MHz BW
5.4 GHz Universal 5470-5900* No Limit No Limit None
5.9 GHz Universal 5900-5950 No Limit No Limit None
5.4 GHz ETSI 5470-5725 27 30 ETSI
5.8 GHz ETSI 5725-5875 30 33 ETSI
5.4 GHz FCC 5470-5725 27 30 FCC
5.8 GHz FCC 5725-5875 36 36 None
5.4 GHz Australia A 5490-5585 24 27 Normal FCC
5.4 GHz Australia B 5655-5725 24 27 Normal FCC
5.8 GHz Australia 5730-5840 33 36 None
5.8 GHz UK 5725-5845 30 33 Normal ETSI
