4.5.3.5.7 Band Name
The Band Name to be used. In all units operating in the licensed 2.x or 3.x GHz
bands only a single Band Name is applicable, according to the unit’s HW
properties. In 5GHz units several Band Name options are available to support
different local regulations.
The default for 4.9 GHz units is 4.9 GHz Universal.
The default for 5.4 GHz units is 5.4 GHz Universal.
The parameters that are affected by the selected Band Name are:
 Supported frequency range. For details refer to “Frequency” on page 125.
 Maximum EIRP allowed by regulations. This parameter affects the allowed
range for Tx Power. For more details refer to “Tx Power” on page 126.
 Required DFS algorithm. For more details refer to “DFS” on page 79.
CAUTION
In 5 GHz units, it is the responsibility of the Administrator to verify that the selected Band Name is in
accordance with relevant local regulations.
Table 4-2: Band Name’s Dependent Parameters, 4.9 GHz Units
Band Name Frequency Range
(MHz)
Maximum EIRP (dBm) Supported
DFS
5 MHz BW 10 MHz BW
4.9 GHz Universal 4900-5350 No Limit No Limit None
4.9 GHz FCC 4940-4990 No Limit No Limit None
4.9 GHz Japan A 4900-5000 34 34 None
4.9 GHz Japan B 5030-5091 34 34 None
5.3 GHz ETSI 5250-5350 20 23 ETSI
5.2 GHz ETSI 5150-5250 20 23 None
5.2 GHz FCC 5150-5250 27 30 None
5.3 GHz FCC 5250-5350 27 30 FCC
5.1 GHz FAA 5090-5150 No Limit No Limit None
