Chapter 4 - Operation and Administration BTS Menu
BreezeMAX Extreme 74 System Manual
its Tx power taking into account the estimated link loss, the number of
sub-channels used and the SNR required for the relevant rate.
» UL / DL Ratio
◊ Current UL / DL Ratio
◊ Configured UL / DL Ratio
» Band Name
◊ Current Band Name
◊ Configured Band Name
» DFS (if applicable)
◊ DFS Type: Read-only, according to the current Band Name. The options
are ETSI, FCC, Normal ETSI, Normal FCC.
◊ Current Frequencies Management Level
◊ Configured Frequencies Management Level
Update: Enables updating the configured values of Radio parameters.
The configurable Radio Parameters include the following:
Operator ID
Operator Name
Service Zone ID
Service Zone Name
Operation Mode
DL / UL Ratio
Band Name
DFS
