Chapter 2 - Installation BTS Installation
BreezeMAX Extreme 35 System Manual
1 Hang the BTS with the tilt bracket on the tilt control screws of the BTS
carriage.
2 Attach and fasten all the screws at both sides of the BTS carriage . Do not over
tighten.
To mount the BTS on the carriage:
Figure 2-8: BTS Mounted on a 1.5''-4'' Pole (with Clamps)
Tilt control screw
