User's Manual

Chapter 2 - Installation BTS Installation
BreezeMAX Extreme 29 System Manual
 8 x M8 nuts
 14 x M8 spring washers
For poles larger than 4'' - additional kit containing 4 metal bands
2.1.2 Assembling the Tilt Bracket on the BTS
The tilt bracket is attached and fastened to the BTS and then hung on the
carriage. After hanging the BTS on the carriage, tilt and rotate the BTS as required
before fastening the screws. The Tilt Bracket supports +7.5°/-10° tilting and ±45°
vertical plane rotation. The BTS has to be vertical to the ground.
Place the tilt bracket on the BTS and fasten its screws (see Figure 2-1 and
Figure 2-2).
NOTE
The lightning arrestors supplied within the GPS kit are not included in the warranty cover provided
for the GPS unit.
Additional lightning arrestors can be ordered separately
NOTE
Install the unit with the bottom panel, including the LEDs, facing downward. Note the direction
arrows (UP) on the sides of the BTS.
CAUTION
The weight of BTS is 10.7 Kg and the weight of the Pole Mounting Kit is approximately 5 kg. Be sure
to plan the installation accordingly. It is recommended to use a harness to lift the units.
Install the unit using the supplied kit only.
To assemble the bracket on the BTS:
