2.1 BTS Installation
The BTS can be installed on straight or angled poles (±45° from upward position)
and on a flat surface, such as walls. GPS and external antenna should be
installed above the BTS. Make sure to allow access to all components and
consider the location of power source.
All the installations options include a tilt bracket which supports:
 Rotation: ±45°
 Tilt: +7.5° to -10°
2.1.1 Installation Requirements
2.1.1.1 Packing List
 BTS (weight: 10.7 Kg.)
 Mounting kit (for 1.5''-4'' poles) including the tilt bracket and carriage
 Sealing Gland Fastening Tool
2.1.1.2 Optional Components
Kit including 4 metal bands for mounting on poles larger than 4''
2.1.1.3 Additional Installation Requirements
The following items are also required to install the BTS:
 Ethernet cable*. Not applicable for 5 GHz units using PoE power supply
option. Available in various lengths.
CAUTION
ONLY experienced installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government regulatory authorities should
install outdoor units and antennas.
Failure to do so may void the BreezeMAX Extreme product warranty and may expose the end user
or Service Provider to legal and financial liabilities. Alvarion and its resellers or distributors are not
liable for injury, damage or regulation violations associated with the installation of outdoor units or
antennas.
