Notes on Maximum Tx Power Limitations for 5 GHz Units:
According to the Band Name being used the maximum allowed Tx Power depends
on the gain of antenna(s) and in some cases also on the bandwidth for ensuring
compliance with the maximum allowed EIRP and spectral density specified in the
relevant regulations.
The following tables show the calculated maximum transmitter power level
according to relevant FCC regulations for 5.4 and 5.8 GHz bands.
The required calculations are performed automatically by the BTS. Actual values
also take into account the maximum Tx power that can be supported by the
hardware (21 dBm) and supported resolution (calculated values are rounded
down to nearest integer).
Table 1-16: Maximum Tx Power @ Antenna Connector, FCC 5.4 GHz
Antenna Type RF Chains/BW Maximum Tx Power (dbm)
Sector, 17dbi 1 RF chain /5MHz 7.7
Sector, 17dbi 2 RF chains/5MHz 4.7
Sector, 17dbi 1 RF chain /10MHz 10.7
Sector, 17dbi 2 RF chains/10MHz 7.7
Internal, 15.5dbi 1 RF chain /5MHz 8.5
Internal, 15.5dbi 2 RF chains/5MHz 8.5
Internal, 15.5dbi 1 RF chain /10MHz 11.5
Internal, 15.5dbi 2 RF chains/10MHz 11.5
Omni, 8dbi 1 RF chain /5MHz 16.7
Omni, 8dbi 2 RF chains/5MHz 13.7
Omni, 8dbi 1 RF chain /10MHz 19.7
Omni, 8dbi 2 RF chains/10MHz 16.7
Table 1-17: Maximum Tx Power @ Antenna Connector, FCC 5.8 GHz
Antenna Type and Gain Maximum Tx Power (dbm)
Internal , dual slant 15.5dbi 20.5
Omni, 9.5dbi 24.2
Sector, 17dbi 19.7
