Chapter 1 - System Description Specifications
BreezeMAX Extreme 23 System Manual
3.5 GHz Radio
ETSI EN 302 326
ETSI EN 302 623
ETSI EN 301 390
CEPT/ERC Recommendation 74-01E
3.65 GHz Radio
FCC Part 90
FCC Part 2
5 GHz Radio
ETSI EN 302 326
ETSI EN 301 390
ETSI EN 302 502 v1.2.1
ETSI EN 301 893 v1.5.1
FCC Part 15.247
FCC Part 15.407
FCC-06-96A1
UK VNS 2107
UK IR200
CEPT/ERC Recommendation 74-01E
Lightning Protection
ITU-T - K.20
EN-61000-4-5
Ethernet
IEEE 802.3 CSMA/CD
IEEE 803.3u
Power Supply Interface (DC) ETSI EN 300 132-2
WiMAX
IEEE 802.16-2004
IEEE-802.16e-2005
Table 1-15: BTS Standards Compliance, General
Type Standard
