Chapter 1 - System Description Specifications
BreezeMAX Extreme 22 System Manual
1.4.10 Configuration and Management
1.4.11 Environmental
1.4.12 BTS Standards Compliance, General
Table 1-13: Configuration and Management
Item Description
Management via Data Port
SNMP
Tel n et
SNMP Agents SNMP ver 1 client
MIB II (RFC 1213), RFC2233, RFC2618, RFC2620, Private MIBs
Software upgrade Using TFTP
Configuration upload/download Using TFTP
Table 1-14: Environmental Specifications
Type Unit Details
Operating temperature BTS -40°C to +60°C
AC/DC Power Supplyt -20°C to +70°C
Operating humidity BTS 5%-95% non condensing
AC/DC Power Supply 20%-90% non condensing
Rain and Dust Ingress Protection BTS IP 67
Table 1-15: BTS Standards Compliance, General
Type Standard
EMC
ETSI EN 301 489-1/4
ETSI EN55022 Class B
FCC Part 15 Class B
Safety
EN 60950-1/22
UL 60 950-1/22
AS/NZS 3260 (Australia / New Zealand)
Environmental ETSI 300 019-2-4 V2.2.2 Class T4.1E
