User's Manual

Chapter 1 - System Description Specifications
BreezeMAX Extreme 18 System Manual
1.4.4 Sensitivity
1.4.5 3.x GHz Antennas
1.4.5.1 Integral 3.x GHz Antennas
1.4.5.2 External 3.x GHz Antennas (Optional)
Table 1-4: Sensitivity, AWGN @ PER=1%, UL Fade Margin=2dB
Modulation &
Coding
Sensitivity (dBm), 5 MHz Bandwidth Sensitivity (dBm), 10 MHz Bandwidth
No Diversity With Diversity No Diversity With Diversity
QPSK 1/2 -95 -98 -92 -95
QPSK 3/4 -92 -95 -89 -92
16QAM 1/2 -89 -92 -86 -89
16QAM 3/4 -85 -88 -82 -85
64QAM1/2 -83 -86 -80 -83
64QAM2/3 -80 -83 -77 -80
64QAM3/4 -79 -82 -76 -79
64QAM5/6 -76 -79 -73 -76
Table 1-5: Integral 3.x GHz Antennas Specifications
Item Description
90° Dual Slant 2 x 13 dBi in the 3.3-3.8 GHz band, 90°AZ x 13°EL sector antenna, 
dual slant +/- 45° polarization, RoHS compliant.
Table 1-6: External 3.x GHz Antennas Specifications
Item Description
BS ANT 60V/3.3-3.8 16.5 dBi minimum in the 3.3-3.8 GHz band, 60° AZ x 7° EL, vertical polarization,
compliant with ESTI EN 302 326-3 V1.2.1 (2007-01).
76.6 x 15 x 8.7 cm, 2.2 kg. Mounting kit: 2" to 4.5" pole.
BS ANT 90V/3.3-3.8 14.5 dBi minimum in the 3.3-3.8 GHz band, 90° AZ x 7° EL, vertical polarization,
compliant with ESTI EN 302 326-3 V1.2.1 (2007-01).
76.6 x 15 x 8.6 cm, 2.2 kg. Mounting kit: 2" to 4.5" pole.
