Chapter 1 - System Description Specifications
BreezeMAX Extreme 17 System Manual
1.4.3 5 GHz BTS
Table 1-3: 5 GHz BTS Specifications
Item Description
Frequency*
(see note below)
 4.9 GHz Band: 4900-5350 MHz
 5.4 GHz Band: 5470-5950 MHz
Supported Bandwidth 5 MHz, 10MHz
Central Frequency Resolution
 2.5 MHz @ 5 MHz bandwidth
 5 MHz @ 10 MHz bandwidth
Tx Power Range*
(see note below)
0-21 dBm, in 1 dBm steps
Tx Power Accuracy +/- 1 dB
Max. Input Power 
(at antenna port)
-50 dBm before saturation
-10 dBm before damage
Dimensions (H x W x D) 510 x 280 x 147mm
Weight (kg) 10.7
Power Source 40 to 60 VDC
Power Consumpltion Single Radio: 41.5W maximum
Two Radios: 57W maximum
NOTE
Actual supported frequencies and Tx power range depend on relevant regulations according to the
Frequency Band being used.
Maximum supported Tx Power depend also on the configured antenna gain and in some cases also
on the bandwidth, according to the maximum allowed EIRP and spectral density specified in the
relevant regulation for the selected Band Name. See also the Notes on Maximum Tx Power
Limitations for 5 GHz Units at the end of the Specifications section.
