User's Manual

Chapter 4 - Operation and Administration Parameters Summary
BreezeMAX Extreme 180 System Manual
Downlink Basic Rate
 QPSK-CTC-1/2 REP4
 QPSK-CTC-1/2 REP2
 QPSK-CTC-1/2
 QPSK-CTC-3/4
 QAM16-CTC-1/2
 QAM16-CTC-3/4
 QAM64-CTC-2/3
 QAM64-CTC-3/4
 QAM64-CTC-5/6
QAM64-CTC-1/2 No
Uplink Fade Margin 0-15 (dB) 2 (dB) No
BS - Channelization
DL Permutation Base
 Fix
 Variable
 Rotated
In current release only Fix is supported
Fix No
DL Permutation Base Value 0-31 0 No
UL Permutation Base
 Fix
 Variable
 Rotated
In current release only Fix is supported
Fix No
UL Permutation Base Value 0-69 0 No
Major Group 0-63. In current release only the default is
supported (63 for BS BW 10 MHz, 21 for
BS BW 5 MHz).)
63 for BS bandwidth
of 10 MHz.
21 for BS bandwidth
of 5 MHz.
No
BS - R6 Interface - Connectivity
BS IP Address IP address No
Table 4-20: BTS Parameters Summary
Parameter Range Default Run-Time
Updated
