4.10 Antenna Menu
According to the capabilities supported by the hardware and (if applicable) the
selected Operation Mode, the unit can use one or two antennas. For Integral
Antennas the parameters are read only and cannot be modified. For External
Antennas the parameters are configurable.
The Antenna menu enables viewing the configured parameters of each Antenna
and modifying the parameters of External Antenna(s).
The Antenna menu includes the following options:
 Show Summary: Select this option to view all relevant parameters of the
Antenna(s).
 Select: Use this option to select the viewing and configuration mode for a
specific Antenna.
4.10.1 Show Summary
Select this option to view all relevant parameters of the configured Antenna(s). For
each of the available Antennas the following details are displayed:
 Antenna ID
 Current Antenna Gain (dBi)
 Configured Antenna Gain (dBi)
 Beam Width (degrees)
 Antenna Polarization
 Antenna Type: Integral or External according to the unit’s type.
Refer to Section 4.10.2.2 for details on these parameters.
NOTE
In configurations that supports a single Antenna only Antenna 1 is available.
