4.8 BS Menu
According to the capabilities supported by the hardware one or two BSs. The BS
menu enables viewing the current and configured parameters of each BS
supported by the unit and modifying these parameters.
The BS menu includes the following options:
 Show Summary: Select this option to view all relevant parameters of the
supported BSs(s).
 Select: Use this option to select the viewing and configuration mode for a
specific BS.
4.8.1 Show Summary
Select this option to view all relevant parameters of the supported BS(s). For each
of the supported BSs the following details are displayed:
 BS Index
 BS ID: A unique identifier of the BS. The BS ID comprises 48 bits displayed in
an IP format as x.x.x.x.x.x (x=0-255).
The BS ID is calculated as follows:
For details on the parameters used for calculating the BS ID refer to:
Operator ID: See “Operator ID” on page 75
NOTE
In the current release only configurations with a single BS (BS 1) are supported.
Table 4-18: BS ID Calculation
Operator ID Cell ID Sector ID
24 bits 16 bits 8 bits
0-255.0-255.0-255 0-255.0-255 0-3
0-16777215 Service Zone ID(11 bits):
0-2047
Cell Number (5 bits):
0-31
Segment
Number: 0-3
