User's Manual

Chapter 4 - Operation and Administration Sector Menu
BreezeMAX Extreme 126 System Manual
* The frequency 5725 MHz is illegal and cannot be used.
4.7.2.2.1.6 Tx Power
The sector’s Tx Power in dBm. The configuration range is from 0 to 50 dBm using
a 1 dB resolution. In 3.x GHz units the actually available range (using 1 dB
resolution) and default are:
The system administrator/installer is responsible for veifying compliance of the
power emotted from the antenna(s) with local regulations and license conditions,
if applicable.
In 4.9 GHz and 5.4 GHz units the HW supports a Tx Power range of 0 to 21* dBm
(* in the current release, in units using 5.9 GHz Universal Band Name the
maximum supported Tx Power is 20 dBm). However, in units using certain Band
Names the actually available Tx Power range depends also on the maximum
allowed EIRP according to relevant regulations and on the configured Bandwidth
and Antenna Gain:
Table 4-14: Frequency Configuration, 5.4 GHz Units
Band Name Frequency Range Default Frequency
5.4 GHz Universal 5470-5900 MHz* 5475 MHz
5.9 GHz Universal 5900-5950 MHz 5905 MHz
5.4 GHz ETSI 5470-5725 MHz 5475 MHz
5.8 GHz ETSI 5725-5875 MHz 5730 MHz
5.4 GHz FCC 5470-5725 MHz 5475 MHz
5.8 GHz FCC 5725-5875 MHz 5730 MHz
5.4 GHz Australia A 5490-5585 MHz 5500 MHz
5.4 GHz Australia B 5655-5725 MHz 5660 MHz
5.8 GHz Australia 5730-5840 MHz 5735 MHz
5.8 GHz UK 5725-5845 MHz 5730 MHz
Table 4-15: Sector Tx Power, 3.x GHz Units
Band Tx Power Range (dBm) Default (dBm)
3.5 GHz 21-30 30
3.65 GHz 17-30 30
