4.7.2.2.1.5 Frequency
The central frequency of the sector in MHz. The available range and default
depend on the frequency band supported by the hardware and the selected Band
Name (5 GHz units) and the selected bandwidth.
The configurable frequencies are from the Minimum Frequency + 1/2 Bandwidth
up to a maximum of the Maximum Frequency - 1/2 Bandwidth.
The resolution for 3.x GHz units is 0.125 MHz.
In 5 GHz units, the frequency resolution is half the selected bandwidth: 2.5 MHz
for a bandwidth of 5 MHz, 5 MHz for a bandwidth of 10 MHz.
In the current release the available bandwidths, ranges and defaults are:
Table 4-12: Frequency Configuration, 3.x GHz Units
Band Name Frequency Range Default Frequency
3.5 GHz 3400-3600 MHz 3405 MHz
3.65 GHz 3650-3700 3655 MHz
Table 4-13: Frequency Configuration, 4.9 GHz Units
Band Name Frequency Range Default Frequency
4.9 GHz Universal 4900-5350 MHz 4905 MHz
4.9 GHz FCC 4940-4990 MHz 4945 MHz
4.9 GHz Japan A 4920-5000 MHz 4905 MHz
4.9 GHz Japan B 5030-5091 MHz 5035 MHz
5.3 GHz ETSI 5250-5350 MHz 5255 MHz
5.2 GHz ETSI 5150-5250 MHz 5155 MHz
5.2 GHz FCC 5150-5250 MHz 5155 MHz
5.3 GHz FCC 5250-5350 MHz 5255 MHz
5.1 GHz FAA 5090-5150 MHz 5095 MHz
