Chapter 4 - Operation and Administration Sector Menu
BreezeMAX Extreme 122 System Manual
Configured Frequency (MHz)
Current TX Power (dBm)
Configured TX Power (dBm)
Sector Antenna's Associations
According to the Operation Mode, the Sector can be associated with either one or
two Antennas. The details displayed for each Antenna associated with the Sector
are:
Antenna ID
Antenna Gain (dBi)
Beam Width (degrees)
Antenna Polarization
Antenna Type
Sector BS's & Radio Channel's Association
The number of associated BSs/Radio Channels depend on the Operation Mode.
The details displayed for each Radio Channel associated with the Sector are:
BS Index
Radio Channel ID
BS ID
BS Name
Supported Frequency Range (according to the details in the Frequency File for
the Frequency Band supported by the unit):
Frequency Band ID
NOTE
In the current release the Sector is associated with one BS (BS1) and one or two Radio Channels.
