4.7 Sector Menu
According to the capabilities supported by the hardware and (if applicable) the
selected Operation Mode, the unit supports one or two sectors. The Sector menu
enables viewing the current and configured parameters of each sector supported
by the unit and modifying these parameters.
The Sector menu includes the following options:
 Show Summary: Select this option to view all relevant parameters of the
supported Sector(s).
 Select: Use this option to select the viewing and configuration mode for a
specific Sector.
4.7.1 Show Summary
Select this option to view all relevant parameters of the supported Sector(s). For
each of the supported Sectors the following details are displayed:
 BTS Operation Mode (for more details see “Operation Mode” on page 75)
 Sector ID (In the current release only Sector 1 is applicable)
Sector General Parameters (for more details see Section 4.7.2.2 below)
 Sector Name
 Sector Location
 Sector Heading (degrees)
 Current Bandwidth (MHz)
 Configured Bandwidth (MHz)
 Current Frequency (MHz)
NOTE
In the current release only configurations with a single Sector (Sector 1) are supported.
