Chapter 4 - Operation and Administration ASN-GW Menu
BreezeMAX Extreme 116 System Manual
In RADIUS Access-Request messages Attribute 31 is set by default to CPE MAC
Address. The configurable Attribute 31 parameter is applicable only for RADIUS
accounting messages.
The available options are None, CPE MAC Address and CPE Fully Qualified
Domain Name.
The default option is CPE MAC Address.
4.6.2.8.6 Attribute 32
The Attribute 32 parameter is applicable for all DHCP operation modes, defining
information that should be used by the embedded RADIUS client.
Attribute 32 specifies the NAS Identifier information to be included in RADIUS
Access-Request and Accounting-Request messages. This feature enables service
providers to provide more information about the device serving the call originator
to the RADIUS server(s). The information provided by this feature can also be used
for additional security checks.
In RADIUS Access-Request messages Attribute 32 is set by default to BTS ID. The
configurable Attribute 32 parameter is applicable only for RADIUS accounting
messages.
The available options are None, BTS MAC Address, GIADDR, Service Interface
VLAN, Management IP Address, BS ID, BTS Name, Free Text. If the Free Text
option is selected, a unique string of 1 to 32 characters should be specified.
The default option is None.
4.6.2.8.7 Attribute 32 Free Text
Applicable only if the selected option for Attribute 32 is Free Text. A string of 1 to
32 characters to be used as a unique NAS ID in relevant RADIUS accounting
messages.
The default is an empty string (must be configured to a valid value if Free Text is
the selected option for Attribute 32).
4.6.2.9 Service Interfaces
The Service Interface menu enables managing the parameters of the interface
used by the NPU on the network side for a service using a specific Service
Interface. Up to 1024 different Service Interfaces can be defined.
NOTE
In the current release only IP CS Service Interfaces are supported. The references to Ethernet CS
Service Interface in the following sections are not relevant in the current release.
