Chapter 4 - Operation and Administration ASN-GW Menu
BreezeMAX Extreme 115 System Manual
4.6.2.8 Service Groups
A Service Group defines the DHCP mode to be used for acquiring IP address
configuration for the MS provisioned with the relevant Service and, if applicable,
for other devices behind the MS. It also defines additional parameters that affect
the communication between the ASN-GW and an external DHCP server, if
applicable. The Service Group’s parameters includes also the Attributes to be
used for communication with a RADIUS Accounting server.
Up to 10 different Service Groups can be defined.
Each Service Group includes the following parameters:
4.6.2.8.1 Service Group ID
This is an auto-sequential number from 1 to a maximum of 10, generated
automatically during creation of a new Service Group.
4.6.2.8.2 Service Group Name
The Name of the Service Group. A unique string of 1 to 32 characters.
4.6.2.8.3 DHCP Type
In the current release only Transparent mode is supported.
4.6.2.8.4 Nomadic Mode
The Nomadic Mode parameter ia applicable only in Transparent DHCP operation
mode. It defines whether nomadic operation of the MS should be supported by the
provisioning and accounting mechanism. When disabled, the provisioned services
should be supported only when the MS is served by a specific BTS. When enabled,
provisioned services should not be restricted to a specific BTS.
The default is Disable.
4.6.2.8.5 Attribute 31
The Attribute 31 parameter is applicable for all DHCP operation modes, defining
information that should be used by the embedded RADIUS client.
Attribute 31 specifies the Calling Station ID information to be included in RADIUS
Access-Request and Accounting-Request messages. This feature enables service
providers to provide more information about the call originator to the RADIUS
server(s). The information provided by this feature can also be used for additional
security checks.
NOTE
In the current release only Transparent DHCP is supported. Other DHCP Types and their
components are not supported in the current release.
