Chapter 4 - Operation and Administration ASN-GW Menu
BreezeMAX Extreme 114 System Manual
certain Multiple Service Flow, should not overlap with the range values of
any Classifiers of the same Type for the same direction assigned to other
Service Rules assigned to the same Multiple Service Flow.
ยป The MS level: The range values defined for any Classifier of a certain Type
for a certain direction assigned to a Service Rule of any Multiple Service
Flow assigned to any Service for a certain MS, should not overlap with the
range values of any Classifiers of the same Type for the same direction
assigned to any of the Service Rules assigned to other Multiple Service
Flows that are assigned to other Services for the same MS.
Each Classifier includes the following components:
4.6.2.7.1 Uplink/Downlink Classifier Type
This parameter defines the type of classifier to be used in the applicable direction.
Different classifier types may be defined for the uplink and downlink directions.
The available options in the current release are Any and DSCP.
For a Classifier Type Any there are no other parameters.
4.6.2.7.2 Uplink/Downlink Classifier Parameter 1 and 2
Each Classifier of any type other than None can define a range of value to be used
for classification. These parameters defines the lowest and highest values in the
range. The applicable range for DSCP classifier is from 0 to 63.
The value configured for Parameter 2 for a certain direction cannot be lower than
the value configured for Parameter 1 for the same direction.
Note that the value configured for any of these parameters cannot be within the
ranges defined for other Classifiers of the same Type and Direction assigned to
either the same Service Rule, or to other Service Rules assigned to the same
Multiple Service Flow.
NOTE
In the current release only Classifiers of Types None and DSCP are supported. Other Classifier
Types that will be applicable only for Ethernet CS Service Interfaces are not supported in the current
release.
Table 4-9: Classifier Parameters
Uplink/Downlink
Classifier Type
Uplink/Downlink
Classifier Parameter 1
Uplink/Downlink
Classifier Parameter 2
Any - -
DSCP Lowest DSCP Value Highest DSCP Value
