The menu for a selected MS Service enables also viewing the Service Counters for
the selected MS Service.
4.6.2.2.1 MS MAC Address
The MAC Address of the MS to which the Service is provisioned.
4.6.2.2.2 Service Number
The Number of the Service. Each MS can be provisioned with up to 3 Services,
with Numbers from 1 to 3.
4.6.2.2.3 Admin Status
The Admin Status of the Service: Enable or Disable. A disabled Service will not be
available to the end-user, but its properties are maintained in the database
allowing quick renewal of the Service.
4.6.2.2.4 Multiple Service Flow Name
The name of the Multiple Service Flow associated with the Service. Must be a
name of a previously defined Multiple Service Flow that exists in the database.
4.6.2.2.5 Service Profile Name
The name of the Service Profile associated with the Service. Must be a name of a
previously defined Service Profile that exists in the database.
A Management Service Profile must be associated with each MS. Up to two
additional Data and/or VoIP Service Profiles can be associated with each MS (all
combinations of one or two Service Profile types are allowed-one Data, one VoIP,
two Data, two VoIP, one Data and one VoIP).
4.6.2.2.6 MS Service Counters
The Service Counters for a selected MS Service include the following counters for
each existing Service Rule:
 Service Rule Number
 UL Total Received Bytes
 UL Total Received Packets
 UL Total Lost Packets
IMPORTANT
The MAC Address must be one that exists in the database. Refer to ““MS Menu”
on page 165 for details on manually adding MSs to the database.
