AP-10, SA-10, SA-40, WB-10, & D Model Bridges SA-PCR / SA-PCD
PRODUCT FEATURES
Data rate Up to 3 Mbps Up to 3 Mbps
Net throughput Up to 1.8 Mbps Up to 1.6 Mbps
Aggregate Over 15 Mbps (overlapped cells)
Range
Integrated antennas 3,000 ft. (1,000 meters) 3,000 ft. (1000 meters)
External antennas 6 miles US/FCC 6 miles US/FCC
Office environment 500 ft. (150 m) 500 ft. (150 m)
High speed roaming Up to 60 mph (90 km/h) Up to 60 mph (90 km/h)
No. of APs per wired LAN Unlimited
Max. no. of Co-located
cells (access points) 15
Load sharing support Yes Yes
WIRED LAN INTERFACE
Compliant with Ethernet/IEEE 802.3 CSMA/CD
Physical interface 10BaseT Type II PC Card slot
Connector type RJ-45 Type II PC Card slot
Network Operating Systems ALL Windows 95, 98, NT & CE, NetWare, DOS
Network Drivers NDIS 2, NDIS 3, NDIS 4, ODI
Wireless LAN Interface Compliant with IEEE 802.11 Compliant with IEEE 802.11
RADIO SPECIFICATIONS
Type Frequency Hopping Spread Spectrum Frequency Hopping Spread Spectrum
Frequency Range 2.4 GHz - 2.4835 GHz Industrial, 2.4 GHz - 2.4835 GHz Industrial,
Scientific, Medical band Scientific, Medical band
Antenna System Dual diversity Dual diversity
Transmitted Power
Integrated antennas 10 mW or 100 mW (20 dBm) EIRP 100 mW (20 dBm) EIRP
External antennas 50 mW (17 dBm) at the connector
Up to 36 dBm EIRP for 24 dBi antenna
Sensitivity @1 Mbps -83 dBm -83 dBm
@ 2 Mbps -75 dBm -75 dBm
@ 3 Mbps -67 dBm -67 dBm
Modulation 2, 4, 8 Multilevel GFSK 2, 4, 8 Multilevel GFSK
Demodulation DSP based w/adaptive equalization DSP based w/adaptive equalization
Approvals of Compliance FCC part 15, ETS 300-328, FCC part 15, ETS 300-328,
UL, UL/C,TUV/GS, CE UL, UL/C,TUV/GS, CE
CONFIGURATION & MANAGEMENT
Configuration and Setup Via local monitor port (serial RS-232) and SNMP Via PC-based software
Site Survey Via local monitor port (serial RS-232) Via PC-based software
LED indicators Power on, Wired LAN activity, Link status, data traffic
Wireless LAN synchronization,
Wireless LAN signal Quality/load
SNMP management Yes
S/W upgrade Yes, using TFTP download Yes, using PC
ELECTRICAL
External power supply 100 V - 250 V, 50 - 60 Hz 0.5 A From PC Card slot
Input Voltage 5 VDC 5 VDC
Power Consumption 1.5 A (peak) TX: 360 mA/RX: 285 mA
Power Save Mode Avg. TX & RX less than 30 mA
SIZE & WEIGHT
Dimensions (w/o antennas) 5.1" x 3.4" x 1.35" (13cm x 8.6cm x 3.4cm) Standard Type II PC Card
Weight 0.9 lb (0.4 kg) 1.1 Oz (32g)
ENVIRONMENTAL
Operating temperature 32° F - 105° F (0° C - 40° C) 32° F - 105° F (0° C - 40° C)
Operating humidity 5% - 95% non condensing 5% - 95% non condensing
Leading wireless technology
BreezeCOM is a leader in the development and production of wireless communications products for
telecommunications, data communications and wireless LAN applications. Our high performance
products use frequency-hopping, spread-spectrum radio technology and operate in the license-free
2.4 GHz ISM (industrial, scientific and medical) band. BreezeNET products are extremely reliable,
easy to install and offer an exceptionally cost-effective way to add connectivity in your organization.
