eBook Reader Instructional Manual aluratek.com AEBK01FS mnl M10168 Copyright © 2011 Aluratek, Inc. All Rights Reserved.
Table of Contents Chapter 1: Introduction 1.1 Overview 1.2 Features 1.3 Package Contents 1.4 Product Overview - Front 1.5 Product Overview - Back 1.6 Product Overview - Bottom & Top 1.7 Product Overview - Power On to Enter Main Menu 1.8 Product Overview - Basic Operation 1.9 Product Overview - Reading Operation 04 05 05 05 06 07 08 08 09 09 Chapter 2: Operating Instructions 2.1 Charging the Battery 2.2 Inserting a Memory Card 2.3 Power On 2.4 To read an eBook on the included memory card 2.
5.5 To Reset the Picture to the Original Size 5.6 To Setup Auto Turn Page (slide show) 5.7 To Start / Stop Background Music Chapter 6: MP3 Player 6.1 To Play Music 6.2 To Show Playlist 6.3 To Turn Off LCD 6.4 To Select Play Mode (repeat one, repeat all, random) 6.5 To Start / Stop Background Music 6.6 To Show the Instruction of the Keys for the MP3 Control Chapter 7: Settings 7.1 To Set the Language for the Unit 7.2 To Set Auto Power Off 7.3 To Set Auto Turn Page 7.4 To Set the Volume 7.5 To Set the Font 7.
Chapter 1: Introduction 1.1 Overview Thank you for choosing Aluratek’s® LIBRE PRO eBook Reader. In addition to making sure only quality materials are used for manufacturing, Aluratek® is also dedicated to provide the best customer satisfaction and support. The goal of Aluratek is to embody “Simple Elegance” in every product it designs, manufactures and sells.
Chapter 1: Introduction 1.
Chapter 1: Introduction 1.
Chapter 1: Introduction 1.
Chapter 1: Introduction 1.6 Product Overview - Bottom & Top Power SD Card Slot Earphone Jack Mini USB Port 1.
Chapter 1: Introduction 1.8 Product Overview - Basic Operation Instellingen Gebruikersinstellingen Systeeminstellingen Interne Bestandsbeheerder SD-kaart Bestandsbeheerder Achtergrondmuziek Press “Up / Down” keys to choose the item required Press “OK” to enter Press “Esc” to return to previous 1.
Chapter 2: Operating Instructions 2.1 Charging the Battery: The battery is not fully charged and it is highly recommended that you charge your LIBRE before you begin using it. Note: Using the LIBRE “out of the box” will not harm the device. You will experience reduced battery life as the unit will not be fully charged. Connect the power adapter to the LIBRE’s USB port and you will see an animation of a battery charging on the LIBRE’s display.
Chapter 2: Operating Instructions 2.3 Reading books on your LIBRE: There are 100 english language books preloaded on the internal memory. To access these 100 free books: 1. Select “Ebooks” then press “OK” 2. Select the desired book from the list then press “OK”. Your book should load at this time. To turn pages use the page turn buttons located on the lower left of the LIBRE or use the page turn slider (See diagram) “To zoom or enlarge the font” press the magnifying glass on the lower right of the LIBRE.
Chapter 2: Operating Instructions drive letter for the SD card slot is usually one letter higher than the internal memory’s drive letter. (Note: you will only see the removable drive icon for the SD card slot if you have a SD card inserted) Copy and paste or drag and drop the free ebooks, MP3 music and photo files from your PC to either the internal memory or the SD card removeable drive icons.
Chapter 2: Operating Instructions of the LIBRE for 3 seconds using a paperclip or toothpick. Please DO NOT use a pen or pencil, it may not engage the RESET button properly. If the RESET button is engaged properly, the LIBRE will power OFF and the display will go blank. Then power ON the LIBRE by pressing and holding the POWER button until the Aluratek logo shows on the screen and then release the POWER button. The Main Menu should display shortly thereafter.
Chapter 3: Recent Readings eBook Recent Readings eBooks Pictures MP3 Player Settings Help Main menu screen 3.1 Recent Readings To read a book that you read recently: 1. Select “Recent Readings” from the main menu and press “OK” 2.
Chapter 4: eBooks 4.1 To Read an eBook 1. Select “eBooks” from the main menu and press “OK” 2. Select the desired book from the list and press “OK” While reading a book, you can also select these options. 4.2 To Go to a Particular Bookmark 1. Press “ ” and select “Bookmark List” using the arrow buttons (or the “1” button) and press “OK” 2. Select the desired book using the arrow buttons and press “OK” 4.3 To Bookmark a Page 1.
Chapter 4: eBooks 4.6 To Jump to a Certain Page 1. Press “ ” and select “Jump To” using the arrow buttons (or the “4” button) and press “OK” 2. Enter the page number and press “OK”. 4.7 To Change a Font Size 1. Press “ ” and select “Setting” using the arrow button (or the “5” button”) and press “OK” 2. Select “Font Size” and press “OK” 3. Select the desired font size and press “OK” 4.8 To Setup Auto Turn Page 1. Press “ ” and select “Setting” using the arrow button (or the “5” button”) and press “OK” 2.
Chapter 4: eBooks 4.11 To Set the Alignment 1. Press “ ” and select “Setting” using the arrow button (or the “5” button) and press “OK” 2. Select “Alignment” using the arrow button and press “OK” 3. Select the desired alignment and press “OK” 4.12 To Start / Stop Background Music 1. Press “ ” and select “Setting” using the arrow button (or the “5” button) and press “OK”. 2. Select “Background Music” using the arrow button and press “OK” 3.
Chapter 5: Pictures 5.1 To Display Picture 1. Select “Pictures” from the main menu and press “OK” 2. Select the desired picture file and press “OK” While viewing a picture, you can select these options 5.2 To Rotate a Picture 1. Press “ ” and select “Rotate” using the arrow button (or the “1” button) and press “OK”. 5.3 To Zoom In / Out 1. Press “ ” and select “Zoom in” or “Zoom out” using the arrow button (or the “2”, “3” button respectively) and press “OK”. 5.4 To View the Picture in Full Screen 1.
Chapter 6: MP3 Player 6.1 To Play Music 1. Select “MP3 Player” from the main menu and press “OK” 2. Select the desired music file and press “OK” 3. While music is playing, you can press the “page up” or “page down” for previous or next song, you can also adjust the volume by pressing “<” or “>” buttons While listening to music, you can select these options: 6.2 To Show Playlist 1. Press “ ” and select “Playlist” using the arrow button (or the “1” button) and press “OK”. 6.3 To Turn Off LCD 1.
Chapter 7: Settings Select Settings from the main menu. User Settings: 7.1 To Set the Language for the Unit 1. Select “Languages” using the arrow button (or the “1” button) and press “OK”. 2. Select the desired language and press “OK”. 7.2 To Set Auto Power Off 1. Select “Auto Power Off” using the arrow button (or the “2” button) and press “OK”. 2. Select the desired time and press “OK”. 7.3 To Set Auto Turn Page 1. Select “Auto Turn Page” using the arrow button (or the “3” button) and press “OK”. 2.
Chapter 7: Settings 7.8 To Show the Internal Battery Memory Capacity / Usage 1. Select “Memory Capacity” using the arrow button (or the “3” button) and press “OK”. 7.9 To Show the External SD Card Memory Capacity / Usage 1. Select “Card Capacity” using the arrow button (or the “4” button) and press “OK”. 7.10 To Show the Firmware Number of the Device 1. Select “Firmware Version” using the arrow button (or the “5” button) and press “OK”. 7.11 To Restore the System to Factory Default 1.
Chapter 8: Help A copy of this Instructional Manual in PDF format is available under the Help menu of the main menu.
Technical Support If you need further assistance, please contact Aluratek support department prior to returning this device. E-mail: support@aluratek.com Web: www.aluratek.
Radio and TV Interference Statement WARNING!!! This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications.
Warranty Aluratek warrants this product against defect in material or workmanship for 1 Year from the date of purchase. This warranty becomes invalid if the factory-supplied serial number or “warranty void” sticker has been removed or altered on the product. This warranty does not cover: A) Cosmetic damage or damage due to acts of God B) Accident, misuse, abuse, negligence or modification of any part of the product.
Aluratek, Inc. 14831 Myford Rd. Tustin, CA 92780 sales@aluratek.com 714.586.8730 • office 714.586.
