T2428300
Open Frame Transformer
Rev. DST2428300 - 11212012
Overview
Specifications
Input:
• 115VAC50/60Hz,2.7amp.
Output:
• 24VAC/300VA(12.5amp)or28VAC/300VA
 (10amp)supplycurrent.
Electrical:
• Operatingtemperature:---20ºCto49ºCambient.
Electrical (cont’d):
• BTU/Hr.:
 - 24VAC:153.55BTU/Hr.
 - 28VAC:143.31BTU/Hr.
• SystemACinputVAreuirement:310.5VA.
Mechanical:
• Productweight(approx.):7.2lbs.(3.27kg).
• Shippingweight(approx.):8.5lbs.(3.86kg).
Dimensions (H x W x D) (approximate):
2.56”(65.02mm)x3.57”(90.68mm)x2.25”(57.15mm)
T2428300openframetransformerprovidespowerforelectronicpowersupplies
andequipmentincludingsecurity,accesscontrolandsurveillancedevices.
T2428300
