Installation Instructions User Manual

- 6 - eBridge16CR
eBridge16CR Rack Mount Chassis Mechanical Drawing & Dimensions:
(H x W x D approx.) 1.625” x 19.125” x 8.5” (42mm x 486mm x 216mm)
Fig. 6
8.5"
.75"
19.125"
17.625"
1.625"
