Owner's manual

BC600 - Power Supply/Battery Enclosure
Rev. DSBC600 - 04162016
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
1.5”
(38.1mm)
1.0”
(25.4mm)
4.625”
(117.475mm)
1.0”
(25.4mm)
1.0”
(25.4mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.0”
(25.4mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
8.5”
(215.9mm)
18.0”
(457.2mm)
18.0”
(457.2mm)
18.0”
(457.2mm)
6.0”
(152.4mm)
2.5”
(63.5mm)
2.75”
(69.85mm)
2.75”
(69.85mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
14.5”
(368.3mm)
14.5”
(
368.3mm
)
1.0”
(25.4mm)
1.0”
(25.4mm)
14.5”
(368.3mm)
2.5”
(63.5mm)
1.5”
(38.1mm)
2.5”
(63.5mm)
Specifications:
Enclosure Dimensions (H x W x D) (approximate):
18” (457.2mm) x 14.5” (368.3mm) x 4.625” (117.48mm)
BC600
• 19Gaugeredenclosurewithampleknockoutsforconvenientaccess.
• Fitsuptotwo(2)12VDC/17AHbatteriesoruptofour(4)12VDC/7AHbatteries.
• Productweight:10.4lbs.(4.72kg).
• Shippingweight:12.9lbs.(5.85kg).
