Inc. Convection Oven User Manual

S I T E I N S T A L L A T I O N
I N S T A L L A T I O N
WEIGHT
MODEL NET WEIGHT SHIP WEIGHT
767-SK/III 196 lb (89 kg) 216 lb (98 kg) EST.
1767-SK/III 359 lb (163 kg)
EST. 399 lb (181 kg) EST.
28-5/8" (726mm)
Shown with
optional bumper
34-7/8" (886mm)
56-15/16" (1445mm)
E
lectrical
C
onnection
54-13/16" (1376mm)
12-7/8"
(327mm)
26-5/8" (676mm)
25-3/4" (654mm)
28-1/4" (717mm)
*31-13/16" (807mm) - with optional 2-1/2" casters
*35-1/4" (894mm) - with optional 5" casters
*34-7/16" (874mm) - with optional 6" legs
31-3/4" (805mm)
30-7/8" (784mm)
(electrical connection)
26-15/16" (683mm)
33-1/2" (851mm)
with 3-1/2" casters*
25-3/4"
(653mm)
62-3/8" (1583mm)
with 5
" Casters
23-5/8"
(600mm)
*60-15/16" (1548mm) - with optional 3-1/2" (89mm) casters
*62-1/2" (1589mm) - with optional 6" (152mm) legs
28-3/16"
(716mm)
54-3/4" (1390mm)
34-1/2" (876mm)
56-3/4" (1441mm)
with optional bumper
31-9/16"
(801mm)
59-1-2" (1511mm)
24-1/8"
(613mm)
12-7/8"
(326mm)
Electrical
Connection
Shown with
O
ptional
B
umper
767-SK/III 1767-SK/III
CAPACITY PER COMPARTMENT
100 lb (45 kg)
MAXIMUM
VOLUME MAXIMUM
: 53 QUARTS (67 LITERS)
PG. 4 767-SK/III, 1767-SK/III, 2800-SK/III INSTALLATION/OPERATION/SERVICE MANUAL
