Intera Video+Audio to Twisted Pair (UTP) Transmitter User Guide
Table Of Contents
- PRECAUTIONS / SAFETY WARNINGS
- 1.1 GENERAL
- 1.2 INSTALLATION
- 1.3 CLEANING
- 1.4 FCC NOTICE
- ABOUT YOUR DS801-110
- TECHNICAL SPECIFICATIONS
- PRODUCT DESCRIPTION
- APPLICATION DIAGRAMS
- DIAGRAM 1: TYPICAL SETUPS
- DIAGRAM 2: INTERNAL VIEW
- INSTALLING YOUR DS801-110
- OPERATION
- TROUBLESHOOTING GUIDE
- 8.1 NO DISPLAY
- 8.2 NO SOUND
- ALTINEX POLICIES
- 9.1 LIMITED WARRANTY/RETURN POLICIES
- 9.2 CONTACT INFORMATION
SPECIAL APPLICATION
400-0438-005
4
MECHANICAL DS801-110
Housing 0.036” Aluminum
Front Panel 0.035” Steel
Length 4.10 in (104 mm)
Width 1.38 in (35 mm)
Height 1.20 in (30 mm)
Weight 0.25 lb (0.113 kg)
T° Operating 10°C-50°C
T° Maximum 75°C
Humidity 90% non-condensing
MTBF (calc.) 38,000 hrs
Table 2. DS801-110 Mechanical
ELECTRICAL DS801-110
Input
Video Analog Signal 1.0 Vp-p max.
Video Sync Level TTL
Audio Signal Level 1.0 Vp-p max.
Output
Video+ Stereo Audio
Video/Sync/Audio Signals
ALTINEX Standard
Power Consumption
External Adapter: 9 VDC 310 mA (2.8 W)
Table 3. DS801-110 Electrical
