SPECIAL APPLICATION MANUAL PART NUMBER: 400-0438-005 DS801-110 INTERA® COMPUTER/COMPONENT VIDEO + AUDIO TWISTED PAIR (UTP) TRANSMITTER
SPECIAL APPLICATION TABLE OF CONTENTS Page PRECAUTIONS / SAFETY WARNINGS ............... 2 GENERAL..........................................................2 INSTALLATION .................................................2 CLEANING.........................................................2 FCC NOTICE .....................................................2 ABOUT YOUR DS801-110....................................... 3 TECHNICAL SPECIFICATIONS ............................ 3 PRODUCT DESCRIPTION ...................
SPECIAL APPLICATION PRECAUTIONS / SAFETY WARNINGS 1.4 FCC NOTICE 1 Please read this manual carefully before using your DS801-110. Keep this manual handy for future reference. These safety instructions are to ensure the long life of your DS801-110 and to prevent fire and shock hazards. Please read them carefully and heed all warnings. • 1.1 GENERAL • • Qualified ALTINEX service personnel or their authorized representatives must perform all service. 1.
SPECIAL APPLICATION ABOUT YOUR DS801-110 2 TECHNICAL SPECIFICATIONS DS801-110 Intera Video+Audio to Twisted Pair (UTP) Transmitter Specifications are subject to change. See www.altinex.com for up-to-date information. The DS801-110 provides a means of transmitting computer video and audio signals over Twisted Pair-type (CAT-5/6) cable when used together with an ALTINEX UTP receiver, such as the DS801-111 or DA1931CT. GENERAL The DS801-110 is compact and easy to use.
SPECIAL APPLICATION MECHANICAL Housing DS801-110 ELECTRICAL 0.036” Aluminum Front Panel DS801-110 Input 0.035” Steel Video Analog Signal 1.0 Vp-p max. Length 4.10 in (104 mm) Video Sync Level TTL Width 1.38 in (35 mm) Audio Signal Level 1.0 Vp-p max. Height 1.20 in (30 mm) Output Weight 0.25 lb (0.113 kg) Video+ Stereo Audio T° Operating 10°C-50°C Power Consumption T° Maximum 75°C Humidity External Adapter: 9 VDC 90% non-condensing MTBF (calc.) Table 3.
SPECIAL APPLICATION PRODUCT DESCRIPTION 400-0438-005 4 5
SPECIAL APPLICATION APPLICATION DIAGRAMS 5 DIAGRAM 1: TYPICAL SETUPS DS801-110 DS801-111 DS801-110 DA 400-0438-005 6 19 31 CT
SPECIAL APPLICATION DIAGRAM 2: INTERNAL VIEW DS801-110 INPUT OUTPUT HOR SYNC PROCESSING VER VIDEO 15-PIN HD RED PAIR 1 BLUE PAIR 3 GREEN PAIR 2 PLUG and PLAY AUDIO STEREO 3.5mm LEFT AUDIO MODULATION RIGHT CLOCK GENERATOR POWER 2-PIN TERM.
SPECIAL APPLICATION INSTALLING YOUR DS801-110 6 OPERATION Step 1. Determine the best location for the DS801-110 and TP Receiver. Where possible, locate the DS801-110 as close to the video source as possible and the receiver as close to the receiving component as feasible. The DS801-110 requires no adjustments for operation. Once connected, the DS801-110 will work trouble-free with no user intervention.
SPECIAL APPLICATION 8.2 NO SOUND ALTINEX POLICIES Cause 1: The source has a problem. Solution: Check the source and make sure that there is a signal present and all source connections are correct. If the source is working and there is still no sound, see Cause 2. 9.1 LIMITED WARRANTY/RETURN POLICIES Please see the ALTINEX website at www.altinex.com for details on warranty and return policies. 9.2 CONTACT INFORMATION Cause 2: The volume is too low. ALTINEX, Inc.
