Installation guide

IPDP - installation and operating instructions
36
4 Technical Parameters
4.1 Electrical Parameters
Parameter
Value
Conditions
Communication interface
Ethernet 10BaseT, 100BaseTx
VoIP protocol supported
SIP
Video
série JPEG, stream H.263 (H.264)
Band width
300Hz – 3400 Hz
Power supply - adapter
12Vss ± 2V , 12Vst ± 1V
- or PoE
IEEE802,3af Altern. A+B
Max. consumption
300mA
12Vss
Max. voltage of switch contact
48V
at I < 1A
Max. current of switch contact
2A
at U < 30 V
Operational temperature
- 20 to + 70°C
4.2 Mechanical dimensions
Panel
Flush mounted
installation box
Surface mounted
installation box
Weater protection
hoods
valid for dimensions of
all ref numbers of all
panels with height 1
(series 1)
ref. F08843
ref. F7061
for one panel – ref.
F8400
130(w)x128(h)
115(w)x114(h)x45(d)
130(w)x114(h)x33(d)
135(w)x130(h)
for two panels – ref.
8408
265(w)x130(d)
4.3 Parameters of video
Video for WEB:
InternetExplorer - (series JPEG pictures) is using again and again repeated
http request ADDRESS/video.jpg
Mozilla, Opera, Firefox … and program PopUp (UDVguard) - (MJPEG
stream) is using http request ADDRESS/video.mjpg (sometimes it is necessary
reload beyond with it start).This video is continuously and has smaller load of
nets.
Stream video for IP phones:
H.263 IPDP doorphone and videophone communicate over SIP/SDP protocol
on standard SIP port and video (and sound) then run in RTP protocol on port
talk to SIP.
