2.0 Requirements
The following sections identify the detailed requirements of the 802.11n Draft 2.0 USB Dongle.
2.1 Functional Block Diagram
2.2 General Requirements
2.2.1 IEEE 802.11b Section
# Feature Detailed Description
2.2.1.1 Standard
y
IEEE 802.11b
2.2.1.2 Radio and
Modulation
Schemes
y
DQPSK, DBPSK, DSSS, and CCK
2.2.1.3 Operating
Frequency
y
2400 ~ 2497MHz ISM band
2.2.1.4 Channel Numbers
y
11 channels for United States
13 channels for Europe Countries and other regions
2.2.1.5 Data Rate
y
11, 5.5, 2, and 1Mbps
2.2.1.6 Media Access
Protocol
y
CSMA/CA with ACK
2.2.1.7 Transmitter Output
Power
y
Typical RF Output Power (tolerance +-2 dB) at each RF chain, Data
Rate and at room Temp. 25degree C
y
17 dBm at 1,2,5.5,11Mbps
Note: The maximum power setting will vary according to individual country regulations.
2.2.1.8 Receiver Sensitivity
y
Typical Sensitivity at each RF chain. Frame (1000-byte PDUs) Error
Rate = 8%
y
–94dBm at 1Mbps
y
–92dBm at 2Mbps
y
–90dBm at 5.5Mbps
2:eCn!
2400 ~ 2483.5MHz ISM band
T
he following sections identify the detailed requirements of the WLAN Card.
