# Feature Detailed Description
7 65 135 72.2 150
8 13 27 14.444 30
9 26 54 28.889 60
10 39 81 43.333 90
11 52 108 57.778 120
12 78 162 86.667 180
13 104 216 115.556 240
14 117 243 130.000 170
15 130 270 144.444 300
2.2.3.5 Media Access
Protocol
y
CSMA/CA with ACK
2.2.3.6 Transmitter Output
Power at Antenna
Connector
y
Typical RF Output Power (tolerance +-2dB) at each RF chain, Data
Rate and at room Temp. 25degree C
y
Note: The maximum power setting will vary according to individual country
regulations

2.4GHz Band/HT-20
y
16dBm at MCS0/1
y
16dBm at MCS2/3
y
15dBm at MCS4/5
y
14dBm at MCS6/7

2.4GHz Band/HT-40
y
15dBm at MCS0/1
y
15dBm at MCS2/3
y
14dBm at MCS4/5
y
13dBm at MCS6/7
2.2.3.7 Receiver Sensitivity
at Antenna
Connector
y
Typical Sensitivity at Which Frame (1000-byte PDUs) Error Rate =
10% and at room Temp. 25degree C

2.4GHz Band/HT-20
y
–86dBm at MCS0/8
y
–84dBm at MCS1/9
y
–82dBm at MCS2/10
y
–80dBm at MCS3/11
y
–78dBm at MCS4/12
y
–76dBm at MCS5/13
y
–74dBm at MCS6/14
y
–72dBm at MCS7/15

2.4GHz Band/HT-40
y
–87dBm at MCS0/8
y
–83dBm at MCS1/9
y
–81dBm at MCS2/10
y
–78dBm at MCS3/11
y
–76dBm at MCS4/12
y
–72Bm at MCS5/13
y
–70dBm at MCS6/14
y
–68dBm at MCS7/15
2.2.4 General Section
# Feature Detailed Description
2.2.4.1 Antenna Type
y
External antenna
