User's Manual

# Feature Detailed Description
MAC processing delay, and CCA detect time (< 4 µs).
2.3.6
Transmit Spectrum
Mask

Refer to sub clause 17.3.9.2, IEEE 802.11a
0dBr Bandwidth is less than 18MHz
Min. -20dBr at 11MHz offset
Min. -28dBr at 20MHz offset
Min. -40dBr at 40MHz offset
2.3.7
Out-of-band
Emission
 Refer to FCC Part 15.407, 15.205, and 15.209
 Less than –27dBm EIRP in 1MHZ bandwidth in
unrestricted band
2.3.8
Receiver Sensitivity

Refer to sub clause 17.3.10.1, IEEE 802.11a

Refer to #2.2.1.8
2.3.9
CCA Sensitivity

Refer to sub clause 17.3.10.5, IEEE 802.11a
 The start of a valid OFDM transmission at a receive level
equal to or greater than the minimum 6Mbit/s sensitivity
(-82dBm) causes CCA to indicate busy with a
probability >90% within 4µs.
2.4 Software Requirements
The Configuration Software supports Microsoft Windows 98SE, ME, 2000, and XP. This configuration software
includes the following functions:
 Information
Information allows you to monitor network status.
 Configuration
Configuration allows you to configure parameters for wireless networking.
 Encryption
Encryption provides WEP security control
 Diagnosis
Diagnosis allows you to display all channel status and search neighboring access points
