User's Manual

WMP-N06
# Feature Detailed Description

15dBm at MCS - 5, 13

11dBm at MCS - 6, 14

6dBm at MCS - 7, 15
2.1.3.8 Receiver Sensitivity

Typical Sensitivity at Which Frame (1000-byte PDUs) Error Rate =
10%

–88dBm at BPSK, coding rate 1/2 (MCS-0)

–84dBm at QPSK, coding rate 1/2 (MCS-1)

–81dBm at QPSK, coding rate 3/4 (MCS-2)

–78dBm at 16-QAM, coding rate 1/2 (MCS-3)

–75dBm at 16-QAM, coding rate 3/4 (MCS-4)

–70dBm at 64-QAM, coding rate 2/3 (MCS-5)

–69dBm at 64-QAM, coding rate 3/4 (MCS-6)

–68dBm at 64-QAM, coding rate 5/6 (MCS-7)
2.1.4 General Section
# Feature Detailed Description
2.1.4.1 Antenna Connector

Dual UFL antenna connectors
2.1.4.2 Operating Voltage

3.3VDC +/- 10%
2.1.4.3 Current
Consumption

800mA at continuous transmit mode (2 Tx chains on )

450mA at continuous receive mode (3 Rx chains on )
2.1.4.4 Form Factor and
Interface

Mini-PCI Type IIIA form factor
2.1.4.5 LEDs

External LED function supported
2.2 Software Requirements
The Configuration Software supports Microsoft Windows 98SE, ME, 2000, and XP. This configuration software
includes the following functions:
 Information
Information allows you to monitor network status.
 Configuration
Configuration allows you to configure parameters for wireless networking.
 Security
Supports enhanced security WEP, 802.1x,WPA.
2.2.1 Information
# Feature Detailed Description
2.2.1.1 General
Information

General Information shows the name of Wireless
Adapter, Adapter MAC Address, Regulatory Domain,
Firmware Version, and Utility Version.
2.2.1.2 Current Link
Information

Current Link Information shows the Current Setting
ESSID, Channel Number, Associated BSSID, Network
Type (infrastructure or Ad-hoc network), WEP Status
(enable or disable), Link Status (Connect or Dis-
connect), 802.11g Transmit Speed (6, 9, 12, 18, 24, 36,
48, 54Mbps), 802.11b Transmit Speed (1, 2, 5.5,
11Mbps), Signal Strength, and Link Quality.
2.2.1.3 Site survey

To search the neighboring access points and display the
information of all access points.
2dBi Dipole Antenna: Typical 29.5dBm 
3dBi Dipole Antenna: Typical 29.5dBm
