User's Manual

WMP-N06
# Feature Detailed Description
14 channels for Japan
2.1.1.5 Data Rate

11, 5.5, 2, and 1Mbps
2.1.1.6 Media Access
Protocol

CSMA/CA with ACK
2.1.1.7 Transmitter Output
Power
2.1.1.8 Receiver Sensitivity

Typical –84dBm for 11Mbps @ 8% PER

Typical –90dBm for 2Mbps @ 8% PER
2.1.2 IEEE 802.11g Section
# Feature Detailed Description
2.1.2.1 Standard

IEEE 802.11g
2.1.2.2 Radio and
Modulation
Schemes

BPSK, QPSK, 16QAM, 64QAM, and OFDM
2.1.2.3 Operating
Frequency

2400 ~ 2483.5MHz ISM band
2.1.2.4 Channel Numbers

11 channels for United States
13 channels for Europe Countries
13 channels for Japan
2.1.2.5 Data Rate

6,9,12,18,24,36,48,54Mbps
2.1.2.6 Media Access
Protocol

CSMA/CA with ACK
2.1.2.7 Transmitter Output
Power

Typical RF Output Power at each RF chain, Data Rate
and at room Temp. 25degree C_2dBi/3dBi dipole antenna

19dBm at 6~36 Mbps

18dBm at 48 Mbps

17dBm at 54 Mbps
2.1.2.8 Receiver Sensitivity

Typical Sensitivity at Which Frame (1000-byte PDUs)
Error Rate = 10%

–86dBm at 6Mbps

–86dBm at 9Mbps

–84dBm at 12Mbps

–82dBm at 18Mbps

–78dBm at 24Mbps

–75dBm at 36Mbps

–71dBm at 48Mbps

–70dBm at 54Mbps
2.1.3 High Throughput Section (HT Mode)
# Feature Detailed Description
2.1.3.1 Standard

IEEE 802.11n draft 1.0
2.1.3.2 Radio and
Modulation Type

BPSK, QPSK, 16QAM, 64QAM with OFDM
2.1.3.3 Operating Frequency

2400 ~ 2483.5MHz ISM band
2.1.3.4 Channel Numbers

11 channels for United States
13 channels for Europe Countries
13 channels for Japan
2.1.3.5 Data Rate

From MCS – 0 to MCS –15 as shown in Appendix A
2.1.3.6 Media Access
Protocol

CSMA/CA with ACK
2.1.3.7 Transmitter Output
Power

Typical RF Output Power at each RF chain, Data Rate and at room
Temp. 25degree C_2dBi/3dBi dipole antenna
2dBi Dipole Antenna: Typical 28dBm 
3dBi Dipole Antenna: Typical 28dBm
2dBi Dipole Antenna: Typical 29dBm 
3dBi Dipole Antenna: Typical 28dBm
