User's Manual

WMP-N06
[Step 3] Then Kevin Serial number (see Figure 5)
[步驟 3] 鍵入 Serial Number (如圖 5
(Figure 5)
[Step 4] (a) Plug DUT into MINI PCI / CARD BUS Interface
(b) Plug RF Cable on DUT antenna three point and user a special line
(MAIN-From Left to Right 0.1.2)
[步驟 4] (a) 將待測物插入 MINI PCI / CARD BUS Interface 介面。
(b) 將待測物接上測試線於三個天線端,請使用專用測試線。(MAIN-由左至右 0.1.2)
[Step 5] Click “
Run Production Test Software” to begin test. (See Figure 6)
[步驟 5] 按下” Run Production Test Software”開始測試(如圖 6)。
(Figure 6)
