PARTS LISTING
ITEM#
DESCRIPTION
QUANTITY
1
Upper cabinet
1
2
Round head cross screws
(matched washers)
22
3
Suction abrasive hose
1
4
Left grid - 41804
1
5
Right grid - 41805
1
6
Sealing tape - PSA foam
1
7
Large funnel
1
8
Bracket
1
9
M8*20
32
10
Leg B
1
11
Mounting bracket
1
12
Air regulator with pressure gauge - 4150009
Each 1
13
Assembled latches - 41813
3
14
Welded reflector for falling abrasive - 41814
1
15
Foot pedal – 4150011(does not include
connection fittings)
1
16
Leg reinforcement 1 – 41816
2
17
Leg reinforcement 2 – 41817
2
18
Legs – 41818
3
19
Dust collector – 4150063
1
20
M6*32 round head screws
12
21
Frame for viewing window – 41821
1
22
Outer viewing window – 41822
1
23
Inner viewing window, plexiglass - 41823
1
24
PE film of viewing window – 41824
1
25
Sealing tape of viewing window – 10793 (sold per
foot)
1
26
Rubber seal strip of front opening doorframe –
41826
1
27
Bracket of top light – 41827
1
28
Fluorescent fixture, 1 Lamp 4bulbs – 41828
1
29
Light window – 41829
1
30
PE film of light window – 41830
1
31
Molded rubber seal strip of light window – 41831
1
32
Cover
2
33
Main body of upper cabinet
1
34
Main support poles – 41834
2
35
Support for main pole – 41835
2
36
Plastic conduit for wire
1
37
Front door latch – 41837
2
