AT-GS950/48PS Switch Web Interface User’s Guide
379
Destination MAC
Address
none
xx:xx:xx:xx:xx:xx hex format
Destination MAC Mask
Length
none
1 - 48
VLAN ID none 0 - 4000
802.1p Priority none 0 - 7
Ether Type
none 0000 - FFFF (Hex)
DSCP none 0 - 63
Protocol
none 1 - 255
Source IP Address
none
IPv4 address in xxx.xxx.xxx.xxx hex format;
Source IP Mask
Length
none 1 - 32
Destination IP Address none IPv4 address in xxx.xxx.xxx.xxx hex format;
Destination IP Mask
Length
none
1 - 32
Source Layer 4 Port none 1 - 65535
Destination Layer 4
Port
none
1 - 65535
Profile Action Index none 1 - 72
Policed DSCP
none
0 - 63
Policed-CoS
none 0 - 7
In-Profile Action Index none 1 - 65535
In-Profile Action Deny/
Permit
Permit
Permit/Deny
Out-Profile Action
Index
none
1 - 65535
Out-Profile Action
Deny/Permit
Permit
Permit/Deny
Out-Profile Action
Committed Rate
none
64 - 1000000 kbps/unit
Table 12. AT-S111 Management Software Default Settings (Continued)
Parameter
AT-GS950/48PS
Default Setting
Specifications
